12V Linear Actuator 100mm/4 Inch, GETLITOOL Heavy Duty Electric Linear Actuator 750N/160LBS for Tractors, Camper, Coop Doors Opener, Dormer Opener, RV Electric Door Opener

By Brand : GETLITOOL

Avg Customer Reviews :

Technical Parameters: Material: Aluminum alloy Load capacity: 750N/160LBS Input Voltage: 12V DC Speed: 10mm/s Stroke Length:100mm/4 inch Working frequency: 20% Rated power: 20W, maximum 30W. Push bar Each side contains a travel limit switch. When the telescopic bar runs to the top or to the top, it will automatically disconnect the electricity. The motor will not idle. Cut off the power, it can be stop at any position, with self-locking function. The push rod is driven by a DC motor with a screw drive. The telescopic rod can only be retracted without rotation. The motor is positive and negative. For example, if the positive electrode is stretched and the negative electrode is shrunk, the telescopic direction of the rod can be changed by changing it. Ambient temperature -20 degreeC to +75 degreeC. Standard protection class: IP54. Low noise design, noise level less than 42dB. Please do not disassemble the machine. Product features: drive other objects to push, pull, rise, drop. Product Applications: TV lift tables, massage beds, electric beds, medical chairs, electric equipment, micro-devices, electric sofas, camera frames, cameras and more.
