Product Description :
Genus 1-Phase Electric Energy LCD Sub Meter ( 2 Wire, 240V, 50Hz, 3200 imp/kWh Class-1.0, ISI Mark) - 5-30 Amp. Single Phase Meters 1 phase, 2 wire, class 1, whole current, Tamper proof, Time of Use, Static Electricity meter conforming to IEC-62053-21/23, IEC-62054 and IS 13779. Designed for MT BF 200 years. 24 bit S? Ad Cs for accurate measurement. Measures current in both the elements (Phase & Neutral), makes meter tamper proof. High Energy resolution(4 decimal), reduces energy loss due to power outage. Extra ordinary Anti tamper features Current reversal, Earth tampers Phase/Neutral cut, Neutral Loop, Pure/Chopped DC injection in Phase/Neural circuit. Phase/Neutral cut tamper. Low Starting Current? accuracy ?2.5A to 60A. Extended immunity to HF ,Tested up to 5W RF power Frequency range ( 30?370 MHz). Measures Active energy, Apparent energy , Maximum Demand kW, Maximum demand k VA ,True rms Voltage , True rms Phase Current, True rms Neutral Current, Instantaneous signed Power Factor ,Instantaneous Frequency, Instantaneous Load. Time of use metering, Up to 6 configurable TOU slots & 6 tariffs, 3 types of days, 4 seasons, daylight saving in accordance with IEC 62054. Optical port Hardware compatible to IEC 62056 ?21,With very high BAUD rate 9 . 6 Kb psresulting in a quick downloading of data. TOU function is supported by EPSON?s factory calibrated RTC with an accuracy of up to 3 minutes per year .RTC developed on GENUS feedback has a 32.768 KHz internal crystal with a stability of better than ?5 PPM. Active Pulse outputs & Visual tamper indications. Store 35 days Load profile with kWh, average voltage & average current,for the integration period for integration period of 30 minutes. 6 months history of billing parameters. Supporting Software. The product is shipped with an efficient meter reading program and a highly user friendly base station software URJA for METER data processing. Battery backup for meter reading in the event of power outage.
Product Details :
- Manufacturer : Genus
- Country of Origin : India
- Package Dimensions : 19.9 x 17 x 7 cm; 340 Grams
- ASIN : B08DRP5NQK
Product Features :
- Genus 1-Phase Electric Energy LCD Sub Meter ( 2 Wire, 240V, 50Hz, 3200 imp/kWh Class-1.0, ISI Mark) - 5-30 Amp.
- 1 phase, 2 wire, class 1, whole current, Tamper proof, Time of Use, Static Electricity meter conforming to IEC-62053-21/23, IEC-62054 and IS 13779. Designed for MT BF 200 years.
- 5-30 Amp ,240 Volt, 50Hz ( Brand Name - Genus Power) Accuracy Test OK , Insulation Test OK
- Starting Current Test OK, Power Consumption Test OK
- Repeatability of Errors Test OK (As per IS:13779)
