SAI ROBOTIC LB1403 / KA 2284 / an 6884 / BA6124 Audio Level Indicator Pro Audio Level Indicator Module 10 L.E.D. Adjustable DC 5V-9V Electronic Components Electronic Hobby Kit
from IndianConstructionIndustry.Com in Association with Amazon India
Home»Robotics»SAI ROBOTIC LB1403 / KA 2284 / an 6884 / BA6124 Audio Level Indicator Pro Audio Level Indicator Module 10 L.E.D. Adjustable DC 5V-9V Electronic Components Electronic Hobby Kit
KA2284 / LB1403 Audio Level Indicator Pro Audio level indicator Module Board, Just connect D.C. Power supply through battery snapper and a audio signal from any audio source volume control. The KA2284 / LB1403 Audio level Indicator Module provides a lvisual indication of dynamic Audio level using LEDs.The module uses the KA2284 / LB1403 LED Dot Level Meter Driver IC to implement a logarithmic LED dot indicator display. The display consists of 11 LEDs ? 1 Blue, 6 green and 4 red which are lit in sequence as the input voltage increases. First LED ? Blue is power LED indicates power on of the Circuit. A single-turn potentiometer is used to set the range for the display. Module Connections There is a 4-pin header on the assembly for making connections. 1 x 4 Header VCC = Connect to 5 to 9 V - You can Supply voltage through 9 Volt battery snapper also. GND = Ground. ( Power Supply ) - You can Supply voltage through 9 Volt battery snapper also. GND = Ground. ( Audio Signal ) IN = Audio signal input Feature: The amplitude of the level can be adjusted by variable resistance placed on the circuit board. Specification: Chip: KA2284 / LB1403 Supply voltage: 5V-9V PCB board size: 90mm X 44mm X 10mm Packing weight: 100 gm
Product Details :
Assembly Required : Yes
Material Type(s) : COPPER
Color : Multicolor
Item part number : ALM 710
Manufacturer recommended age : 10 years and up
Manufacturer : SAI ROBOTIC
Country of Origin : India
Product Features :
100% brand new and high-quality.
It is made of premium material,durable and has long service life.
Its 100% impressive and fast working totally hand made circuit.
Complete working, pre-assembled and ready-to-use project
This product comes with detail study material which explains the theory of the project.
