Electricals - Energy Meters Products

• Single Phase , AC input : 85V-265V
• AC Current : 0-100A & Power Factor : 0.00 -1.00
• Energy unit : 0.00 - 99999KWh & Frequency : 50-60 Hz
• Power : 0.0- 3680W & Accuracy : +/-1%
• Dimension : 133x76x53mm & Power Consuming by device <0.3W

• Class 1.0 accuracy,polycarbonate box
• Double side PCB with SMT components
• Not effect by enternal magnet
• low power consumption
• ISI marked

• ISI Certified, 1 Phase, 5-30A, 2 Wire (Copper), 240V, 50Hz, 3200imp/kWh. Class 1.0 High Accuracy (IS 13779-1999, CBIP Report-88 &IEC Standards).
• 6-Digit Bright Back-lit Display Counter Records Most Accurate Error Free Forward Energy Recording Irrespective of Current Direction.
• Multifunctional, Defect-Free, High Surge Resistant, Hackproof, Low Power Consumption, High Insulation Resistance (> 5 M Ohms) & Dielectric Strength (2KV RMS for 1 Min.), Anti-Tamper Features (Phase-Neutral or Main & Load Wire Interchanged, Neutral Missing, DC Immunity, Abnormal Voltage, Earth Load Tamper Indication etc).
• Light Weight, Dust Proof Body, Elegant Poly-Carbonate Casing & Rugged Construction provides High Resistance to UV.
• Warranty: 1 Year by L&T. Long working life upto 10 years.

• Multi-Function: -The multi-function energy meter can test active power, energy, voltage and current. The power test range is 0~10kW, Energy Storage range is 0~9999kWh, the voltage test range is 6.5~100V, and the current measurement range is 0~100A.
• Display: -Large-screen LCD displays voltage, current, active power, and energy at the same time.
• Back-Lit: -The large screen with backlight can be used even in dark environments. A short button can turn the backlight on or off.
• Auto-Shut: -The DC voltmeter is designed with a power alarm threshold and an overload alarm function.
• Storage: -With storage function, it can store measurement data when power is off.

• 2 in 1: - Voltage protector with energy meter is all that is required; With over voltage under voltage protection, the device measures instantaneous RMS Energy as well as Historical Energy readings upto 0-9999 kWh
• Voltage Protector: -It provides various protections to complete house Over Under Voltage Protector and Overload / Current Protection with wide adjustable range (refer manual for complete details)
• Display: -LCD Screen displays the Total Energy (kWh), Real-time current (a), voltage (V), Active power (W)
• Range: -Over-voltage protection: 85-300 V (default 270 V); Under-voltage Protection: - 85-300 V (default 170 in);Over-current Protection: - 1-63A (default 40A); Power on Delay After Power Off: - Default 2 sec, Recovery Time / Recovery voltage gap is adjustable
• Note: - In case of constant tripping, turn off the malignant load protection (Resistive load limit). It can be adjusted from 0.5A~5A and it trip when sense instant increased load

• Accuracy : 1%
• Dimension : 79x43x48m m (76x39)
• AC input : 40V-300V / AC-Power : 0.0- 30000 W
• AC Current : 0-100A /- Energy unit : 0.00 - 99999 Kwh
• Power Factor : 0.00 -1.00 / Frequency : 45.0-65.0 Hz

• HIGH PERFORMANCE POWER METER: 7 in 1 electrical energy meter let you easily know voltage, power factor, current, power, energy, power factor, temperature, using time. The electric meter is equipped with an updated intelligent ARM processor with accurate data and stable running performance. The voltage: AC 50-300V, current: 0-100A, electrical power: 0-30000W, energy: 0.01-19999kwh, power factor: 0-1PF, temperature: -9 degreeC-99 degreeC, time: 0-200h.
• NON-CONTACT INTERACTIVE SENSOR: This voltage meter with buckle design connector, can reduce heating or poor contact, improving accuracy and safety.
• PREMIUM MATERIAL: This 7 in 1 volt meter & amphere meter crafted with premium PC flame retardant material, high temperature resistance, safer to use.
• LCD DISPLAY& EASY INSTALLATION: This 7 in 1 digital voltage meter suitable for most DIN rail mounting. LCD backlight design, eventhough in dark power box, you can also clearly read the data.
• WIDE APPLICATION: The DIN rail mounted volt amp meter can be used in office, school, market, home, industry, laboratory and other fields. Attention: This energy meter can only use to measure 50/60HZ AC electricity . No used to measure square waves, output of inverter, or non-standard sine waves.

• Large-screen -display voltage, current, active power, energy at the same time
• Store energy data when power off(can be reset to 0). The blue backlight can be turned on/off manually
• Apply to power grid voltage 220V with Rated power: 20A / 5000W
• Comes with 6 months warranty

• Large-screen -display voltage, current, active power, energy at the same time
• Store energy data when power off(can be reset to 0). The blue backlight can be turned on/off manually
• Apply to power grid voltage 220V with Rated power: 20A / 5000W
• Comes with 6 months warranty

• L and T Single Phase Electronic Energy Sub Meter LCD Display 5-30A
• Current: 5 - 30 A
• Voltage: 240 Volts
• Accuracy: Class 1 As per IS 13779
• Frequency: 50 Hz

• 6 DIFFERENT DATAS INFO DISPLAYING: Simultaneously calculates 6 parameters, including voltage (40-300V), current (0-100A), power (0-30000W), energy (0-99999kWh), frequency (45-65Hz) and power factor (0-1PF). 6 in 1 Energy Meter of Voltage Meter, Watt Mater, Ampere Meter, Current Meter, Frequency Meter, Power Factor Meter.
• LARGE LCD SCREEN: Our energy meters with a large clear backlight LCD display, 178 degree wide view angle clear visible, make it easy to read and record the data. Great power consumption meter, watt meter & ampere meter is suitable for home, industry.
• DURABILITY AND SAFETY: This digital volt meter & amphere meter adopts quality ABS flame retardant material and high shear rate chip, making it safe and high precision.
• AUTO DATA RETENTIONATION: When there is a power off, the data in this digital energy meter will be sustained automatially. Reset button can clear the present data and restart the new data supervision.
• WIDE APPLICATION: This energy meters is ideal for energy consumption monitor. This digital energy meter is widely applied in home, store, office, school, factory, etc.

• Type: Static Sub Meter Single phase, 2 wire Digital Dispaly
• Poly-carbonate Strong Body
• Low power consumption
• Applications: Residential,Industrial and Commercial Complexes etc.

• 6 in 1 AC Watt Meter: - Check 6 readings, i.e. Voltage (160~275V), current (0~100A), active power (0~25KW), energy (0~9999KWH), frequency and power factor (0~1)
• Display: - Colorful LED display let you read the recorded data clearly even in dark surroundings
• Reset: - You can reset the power meter from a button provided above the display, long press for 10sec to clear the recorded data
• Power Factor: - In case power factor is less than 1, divide wattage (W) by PF to get actual power reading.
• Compact and Din Rail Mounted: - Only 3.6 cm wide and 8 cm long the device occupy minimal space and you can easily place this device in your MCB box (distribution box) as this meter is 35mm din rail mounted
• Warranty: - The products come with 1 year warranty (To claim warranty contact us via call or whatsapp, number available in 'Product Information' section.)

• Size (HxWxD)mm:96x96x50
• Wire Range : 0-999999 KWH
• Power Supply: 230V AC

• Material: Plastic
• Colour: White
• Size (L x B x H): 20 x 20 x 5 cms
• Package contents: 1 Single phase 2 wire electrical energy KWH meter
• Made in India
